Product Description
The SMC VFS5100-5FZ is a 5/2 way pilot operated solenoid valve from SMC's VFS5000 series, featuring metal seal construction and 24VDC coil voltage. This valve is designed for controlling medium and large pneumatic cylinders with internal pilot operation and plug-in base mounting capabilities.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SMC |
| Model/Part Number | VFS5100-5FZ |
| Series | VFS5000 |
| Valve Type | 5 Port Pilot Operated |
| Position | 2 Position Single |
| Coil Voltage | 24VDC |
| Pilot Type | Internal Pilot |
| Operating Pressure | 0.1 MPa to 1.0 MPa |
| Effective Area (Cv) | 2.2 to 5.7 |
| Response Time | 60ms or less |
| Fluid | Air and Inert Gas |
| Operating Temperature | -10°C to 60°C |
| Construction | Metal Seal |
| Mounting Type | Base Mounted |
| Manual Override | Non-locking Push Type |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686468
Manufacturer SMC
Part Number VFS5100-5FZ
Shelf K-42
Model VFS5100-5FZ
MPN VFS5100-5FZ
Type Solenoid Valve
