Product Description
The WAGO 750-363 is a 4th generation ECO EtherNet/IP Fieldbus Coupler that connects the EtherNet/IP fieldbus system to the modular WAGO I/O system. 750-363 is a 4th generation, ECO, 3 EtherNet/IP™ Fieldbus coupler that connects the EtherNet/IP fieldbus system to the modular WAGO I/O system. The Fieldbus coupler detects all connected I/O modules and creates a local process image. It features dual Ethernet interfaces with integrated switch for line topology wiring and supports up to 64 I/O modules without bus extension.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Baldor |
| Model/Part Number | VEUHM3546 |
| Rated Horsepower | 1 HP |
| Base RPM | 1770 RPM |
| Synchronous Speed | 1800 RPM |
| Voltage | 208/230/460V |
| Phase | 3 Phase |
| Frequency | 60 Hz |
| Full Load Amps | 3.1A @ 208V, 3.0A @ 230V, 1.5A @ 460V |
| Frame Size | 56C |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Mounting Type | C-Face Footless |
| Shaft Diameter | 0.625 inches |
| Overall Length | 13.23 inches |
| Service Factor | 1.15 |
| Frame Material | Steel |
| Insulation Class | F |
| Full Load Efficiency | 85.5% |
| Motor Type | 3520M Unit Handling |
| Rotation | Reversible |
| Number of Speeds | 1 |
| Bearings | Ball |
| IP Rating | 44 |
| Weight | 39 lbs |
| Standards Met | UL, CE, CSA |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 3.1A @ 208V, 3.0A @ 230V, 1.5A @ 460V
Manufacturer Baldor
Shaft Diameter 0.625 in
Enclosure Type TEFC
Part Number VEUHM3546
Shelf PR-TOP
Model VEUHM3546
MPN VEUHM3546
Type AC Motor
