Product Description
The Cutler-Hammer 14102A6513 is a COMET series retroreflective photoelectric sensor designed for reliable object detection in industrial automation applications. This 18mm tubular sensor features selectable Light/Dark operation and provides versatile mounting options with its threaded body and flat sides.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Cutler-Hammer |
| Model/Part Number | 14102A6513 |
| Series | COMET |
| Sensor Type | Retroreflective |
| Sensing Range | 0.1 in to 80 ft / 25 ft |
| Input Voltage | 20-264 VAC or 10-50 VDC |
| Output Type | NPN, PNP, or VMOS |
| Wiring | 2, 3, or 4 Wire |
| Housing Diameter | 18mm |
| Mounting Type | Threaded with flat sides |
| Housing Material | Structural polyurethane foam |
| Lens Material | Polycarbonate |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| NEMA Rating | 1, 2, 3, 4, 4X, 6, 12, 13 |
| Certifications | UL, C-UL Listed, CE Approved |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type NPN
Sensor Type Retroreflective
Manufacturer Cutler-Hammer
Enclosure Type NEMA 1, 2, 3, 4, 4X, 6, 12, 13
Part Number 14102A6513
Shelf K-40
Model 14102A6513
MPN 14102A6513
Type Photoelectric Sensor
