Product Description
The Daikin JQ-G03-2E-12 is a direct acting hydraulic pressure control valve designed for sequence valve, unload valve, counterbalance valve, and relief valve applications. This gasket mount type valve features internal or external pilot and drain configurations, providing versatile control options for hydraulic systems.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Daikin |
| Model/Part Number | JQ-G03-2E-12 |
| Valve Type | Direct Acting Pressure Control Valve |
| Mount Type | Gasket Mount Type (G) |
| Nominal Diameter | 3/8 inch |
| Maximum Operating Pressure | 21 MPa (210 kgf/cm²) |
| Pressure Adjustment Range | 3.5 to 14 MPa (35 to 140 kgf/cm²) |
| Maximum Flow Rate | 50 L/min |
| Function Code | 2 (Standard) |
| Pilot Type | Internal or External |
| Drain Type | Internal or External |
| Application | Sequence/Unload/Counter Balance/Relief Valve |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686185
Manufacturer Daikin
Part Number JQ-G03-2E-12
Shelf B-15
Model JQ-G03-2E-12
MPN JQ-G03-2E-12
Type Pressure Control Valve
