Product Description
The Daikin KSO-GO2-4CA-30-EN is a high-performance hydraulic solenoid operated directional control valve designed for industrial applications. This valve realizes exceptional hydraulic performance with high pressure and large flow rate capabilities up to 35 MPa (350 kgf/cm²) and 100 litres per minute. The valve features IP65 ingress protection grade making it suitable for integration into CE compliant equipment with dust and water-proof properties.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Daikin |
| Model/Part Number | KSO-GO2-4CA-30-EN |
| Type | Solenoid Valve |
| Valve Type | Directional Control Valve |
| Coil Voltage | 100VAC |
| Frequency | 50/60Hz |
| Max Pressure | 35 MPa (350 kgf/cm²) |
| Max Flow Rate | 100 L/min |
| Mounting Pattern | D03 |
| Connection Type | Terminal Box |
| Ingress Protection | IP65 |
| Series | KSO-G02 |
| Compliance | CE Standard, ISO Regulations |
| Weight | 1.7 kg (3.75 lbs) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686185
Country/Region of Manufacture Japan
Manufacturer Daikin
Part Number KSO-GO2-4CA-30-EN
Shelf B-15
Model KSO-GO2-4CA-30-EN
MPN KSO-GO2-4CA-30-EN
Type Solenoid Valve
