Product Description
The Littelfuse LFJ600303CID is a Class J fuse block from the POWR-GARD product line designed for 600V AC/DC applications. This indicating fuse block features a 30 amp current rating and 3-pole configuration with box lug terminal connections for secure wire attachment.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Littelfuse |
| Model/Part Number | LFJ600303CID |
| Series | LFJ |
| Product Line | POWR-GARD |
| Fuse Type | Class J |
| Current Rating | 30A |
| Voltage Rating | 600V AC/DC |
| Number of Poles | 3 |
| Connector Type | Box Lug |
| Mounting Style | Bolt-Down; DIN Rail |
| Indication Feature | Yes (Indicating) |
| Material | Thermoplastic |
| Width | 3.25" |
| Wire Range | 6-14 AWG |
| Torque Rating | 2.8 N-m |
| Wire Type | CU Only 60/75°C |
| Short Circuit Rating | 200kA RMS SYM |
| UPC | 079458181784 |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Litte Fuse
Part Number LFJ600303CID
Shelf K-57
Model LFJ600303CID
MPN LFJ600303CID
Type Fuse
