Product Description
The Mitsubishi QD75MH2 is a 2-axis positioning module designed for use with MELSEC-Q Series PLCs. This SSCNET III communication module provides high-speed, high-precision positioning control for automation systems requiring synchronized motion control across multiple axes.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Mitsubishi |
| Model/Part Number | QD75MH2 |
| Product Type | Positioning Module |
| Series | MELSEC-Q |
| Number of Axes | 2 |
| Communication Protocol | SSCNET III |
| Maximum Pulse Output | 4 Mpps |
| Control Units | mm, inch, degree, pulse |
| Location Data | 600 data/axis |
| Interpolation Types | 2-axis linear, 2-axis circular |
| Connector Type | 40-pin |
| Cable Distance | Up to 50m between stations |
| Compatible Servo | MR-J3-B series |
| Positioning Start Time | 3.5-4 ms |
| Height | 98 mm |
| Width | 27.4 mm |
| Depth | 90 mm |
