Product Description
This Pepperl+Fuchs ML17-8-450/115/136 is a diffuse mode photoelectric sensor featuring compact housing, 360° visibility LEDs, and adjustable sensing range. Part of the Tru-Vue™ series, these sensors are designed as economical, compact all-purpose photoelectric sensors with industry-standard housings for simplified mounting. The sensor features 4-in-1 output that auto-selects NPN or PNP, making it ideal for industrial automation applications requiring reliable object detection.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Pepperl+Fuchs |
| Model Number | ML17-8-450/115/136 |
| Series | ML17 Tru-Vue |
| Sensing Method | Diffuse Mode |
| Sensing Range | 10-450mm |
| Adjustment Range | 60-450mm |
| Light Source | Infrared LED (950nm) |
| Supply Voltage | 10-30V DC |
| Output Type | 4-in-1 (Auto PNP/NPN) |
| Output Configuration | Light-On/Dark-On |
| Response Time | ≤ 1.0ms |
| Switching Frequency | 500Hz |
| Connection Type | 4-pin M12 x 1 Connector |
| Housing Material | Polycarbonate (ABS) |
| IP Rating | IP67 |
| Dimensions | 29.3 x 15 x 34.5mm |
| Operating Temperature | -20°C to +55°C |
| Threading | M18 x 1 |
| Indicators | 360° LEDs (Green Power, Yellow Function) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type PNP/NPN
Manufacturer Pepperl-Fuchs
Part Number ML17-8-450/115/136
Shelf N-9
Model ML17-8-450/115/136
MPN ML17-8-450/115/136
Type Industrial Proximity Sensor
