Product Description
| Product version: | 2.1 |
| Approvals: | CE, cULus Listed, TÜV, CCC |
| Application options: | Safety gate monitor, Instantaneous E-STOP monitoring, Limit switch, Delayed E-STOP monitoring |
| Operating modes: | Single-channel, Automatic reset, Dual-channel, Detection of shorts across contacts, Monitored manual reset |
| Product standard: | EN 60947-5-1 |
| Standards: | EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1 |
| Supply voltage (V): | 24,0 |
| Supply voltage type: | DC |
| Terminal style: | Plug-in |
| Terminal type: | Screw terminal |
| Number of instantaneous safety contacts: | 2 |
| Number of delayed safety contacts: | 2 |
| Safety contact delay type: | Delay-on de-energisation |
| Number of auxiliary contacts: | 0 |
| Number of delayed auxiliary contacts: | 0 |
| Number of semiconductor outputs: | 0 |
| Selectable times: | 0.10 s, 0.50 s, 1.00 s, 10.00 s, 15.00 s, 2.00 s, 20.00 s, 25.00 s, 30.00 s, 4.00 s, 6.00 s, 8.00 s |
| Stop category: | 0/1 |
| Max. current at DC13 I (6 cycles/min): | 7.0 A |
| Max. current at AC15: | 5.0 A |
| Width dimension: | 45.0 mm |
| Height dimension: | 94.0 mm |
| Depth dimension: | 121.0 mm |
| Gross weight: | 370 g |
| Net weight: | 360 g |
| Ambient temperature: | -10 - 55 °C |
Other Details
Industrial Parts R Us Inc. will guarantee all items new and used for 30 days after the item has been received. (See Terms and Conditions). The buyer has the option to exchange the item if we have another in stock, or for the purchase price. The buyer is responsible for all return shipping charges. Refunds will be issued upon return of the item. Thank you from Industrial Parts R Us!!!!Product Videos
Custom Field
Country/Region of Manufacture Germany
