Product Description
This Rexroth R900589988 is a high-performance directional spool valve designed for controlling the start, stop, and direction of hydraulic fluid flow. The valve features wet-pin AC solenoids with detachable coils that can be rotated 90 degrees for easy maintenance without opening the pressure chamber.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Rexroth |
| Model/Part Number | Mnr R900589988 |
| Valve Model | 4WE10J3X/CG24N9K4 |
| Nominal Size | 10 |
| Valve Configuration | 4-way, 3-position |
| Maximum Operating Pressure | 4500 psi |
| Maximum Flow Rate | 32 GPM |
| Coil Voltage | 24VAC |
| Solenoid Type | Wet-pin AC with removable coil |
| Mounting Pattern | ISO 4401-05-04-0-05, NFPA D05 |
| Actuator Ports | 4 |
| Weight | 13.07 lbs |
| Operating Temperature | -20°C to +70°C |
| Manual Override | Yes |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Equipment Type Hydraulic Valve
Manufacturer Rexroth
Part Number MNR R900589988
Shelf B-13
Model MNR R900589988
MPN MNR R900589988
Type Hydraulic Valve
