Product Description
The SMC VQC4100-51 is a 5-port, 2-position single solenoid valve from SMC's VQC4000 series. This pneumatic valve features a plug-in base mount design with side porting and metal seal construction for reliable air and inert gas control applications. The valve offers outstanding response times, long service life of up to 100 million cycles, and is capable of driving cylinders up to 160mm diameter.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SMC |
| Model/Part Number | VQC4100-51 |
| Series | VQC4000 |
| Operation Type | Pneumatic |
| Number of Ports | 5 |
| Number of Positions | 2 |
| Valve Function | 2-Position Single |
| Valve Ways & Position | 5 Way 2 Position |
| Coil Voltage | 24VDC |
| Maximum Operating Pressure | 145 PSI (1.0 MPa) |
| Power Consumption | 0.95W (Standard) |
| Effective Area (Cv) | 1.7 (Metal Seal) |
| Mounting Type | Plug-in Base Mount |
| Porting Specification | Side Ported |
| Seal Type | Metal Seal |
| Thread Type | Rc |
| Manual Override | Non-locking Push Type |
| Enclosure Rating | IP67 |
| Suitable Fluid | Air/Inert Gas |
| Service Life | 100 Million Cycles |
| Weight | 0.507 lbs |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer SMC
Enclosure Type IP67
Part Number VQC4100-51
Shelf K-54
Model VQC4100-51
MPN VQC4100-51
Type Solenoid Valve
