WAGO 753-513 2-Channel Relay Output Module 250V AC 2A

The WAGO 753-513 is a pluggable AC digital relay output slice module for the 753 series I/O system. It features 2 normally open relay contacts that are potential-free, rated at 250V AC/30V DC with 2A current capacity. The module operates on 5V DC supply voltage provided by the system and mounts on DIN-35 rail.

Specifications

• 2 digital relay outputs (NO contacts)
• 250V AC / 30V DC, 2A rating
• Potential-free contacts
• 5V DC supply voltage
• DIN-35 rail mounting
• 12mm width x 69.8mm height x 100mm depth
• Push-in spring cage-clamp connections
• 0.5Hz switching frequency
