Product Description
The WEG DWB160B is a molded case circuit breaker from the DWB series designed for protection of motors, generators, electrical circuits and transformers. These circuit breakers feature short-circuit interrupting capacity up to 80kA (380/415V), and a variety of functionalities. The frame size 160 designation indicates the physical mounting dimensions and maximum current capacity range.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | WEG |
| Model/Part Number | DWB160B |
| Product Type | Molded Case Circuit Breaker |
| Series | DWB |
| Frame Size | 160 |
| Maximum Operating Voltage | 690V |
| Short Circuit Interrupting Capacity | Up to 80kA at 380/415V |
| Standard Compliance | IEC 60947-2 |
| Application | Motors, generators, electrical circuits, transformers |
| Current Rating Range | See specific model suffix |
| Available Pole Configurations | 3-pole, 4-pole |
| Trip Unit Options | DX (Fixed thermal/magnetic), DF (Adjustable thermal/magnetic) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Mounting Style Panel Mount
Current Rating 160A
Manufacturer WEG
Part Number DWB160B
Shelf J-6
Model DWB160B
MPN DWB160B
Voltage 690V
Type Circuit Breaker
