Product Description
The Yaskawa CIMR-VU4A0018FAA is a high-quality AC variable frequency drive from the V1000 series engineered to provide reliable motor control in industrial environments. This compact current vector drive delivers optimal performance for demanding applications requiring precise and efficient motor control with advanced protection features.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Yaskawa |
| Model/Part Number | CIMR-VU4A0018FAA |
| Series | V1000 |
| Input Voltage | 380-480V AC, 3-Phase |
| Output Current (Normal Duty) | 17.5A |
| Output Current (Heavy Duty) | 14.8A |
| Rated Power (Normal Duty) | 10 HP (7.5kW) |
| Constant Torque Rating | 7.5 HP |
| Variable Torque Rating | 10 HP |
| Frequency Range | 0.01-400 Hz |
| Enclosure Type | NEMA 1 |
| Dimensions (H x W x D) | 10.0" x 5.51" x 5.51" (254 x 140 x 140 mm) |
| Weight | 7.0 lbs |
| Apparent Power (Normal Duty) | 13.3 kVA |
| Apparent Power (Heavy Duty) | 11.3 kVA |
| Control Type | Open Loop Vector, V/f Control |
| Communication | MODBUS, RS-422/RS-485 |
| Efficiency | >95% |
| Braking | DC Injection, Dynamic Braking Transistor |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to 40°C (NEMA 1) |
| Storage Temperature | -20°C to +60°C |
| Mounting Type | Panel Mount |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Yaskawa
Enclosure Type NEMA 1
Part Number CIMR-VU4A0018FAA
Shelf K-46
Input Voltage 380-480V
Model CIMR-VU4A0018FAA
MPN CIMR-VU4A0018FAA
Type Variable Frequency Drive
