Product Description
The ABB ECS41BC is a solid state current monitoring relay designed for precise current measurement and control in industrial automation applications. This sensor features a built-in toroidal current transformer that eliminates the need for a separate CT, with adjustable trip points and delays for versatile motor protection and monitoring.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | ABB |
| Model/Part Number | ECS41BC |
| Manufacturer | SSAC (Littelfuse) |
| Supply Voltage | 120VAC |
| Current Range Monitored | 2-20A |
| Trip Delay | 0.5-50 Seconds (Adjustable) |
| Contact Configuration | 1C SPDT |
| Contact Rating | 10A |
| Mounting Type | Surface Mount |
| Termination | 0.25in Male Quick Connect Terminals |
| Sensing Type | Overcurrent or Undercurrent |
| Sensor Type | Built-in Toroidal Current Transformer |
| Adjustment Type | Knob Adjust |
| Frequency | 50/60Hz |
| Series | ECS |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Sensor Type Built-in Toroidal Current Transformer
Full Load Amps 2-20A
Manufacturer ABB
Part Number ECS41BC
Shelf N-9
Model ECS41BC
MPN ECS41BC
Type Current Sensor
