Product Description
The Allen-Bradley 2098-DSD-HV050X is an Ultra3000i Digital Servo Drive with built-in indexing capability, designed for high-performance motion control applications. It accepts a wide-range three-phase AC input of 230–480V rms and delivers up to 5.0 kW of continuous output power at 460VAC, making it suitable for a broad range of servo motor and actuator pairings. The drive supports multiple encoder feedback types, analog and digital I/O, and RS-232/RS-422/RS-485 serial communications for integration into Logix, SLC, and third-party control architectures.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Allen-Bradley |
| Model / Part Number | 2098-DSD-HV050X |
| Platform / Family | Ultra3000i (Indexing) |
| Product Type | Digital Servo Drive |
| Input Voltage (AC) | 230–480V rms, Three-Phase |
| Input Frequency | 47–63 Hz |
| Input Current | 7 A |
| Continuous Output Current | 11 A (0-peak) |
| Intermittent Output Current | 22 A (0-peak) |
| Output Current (RMS) | 7.8 A |
| Continuous Output Power @ 230VAC | 2.5 kW |
| Continuous Output Power @ 460VAC | 5.0 kW |
| Rated Power | 5 kW |
| Phase | 3-Phase |
| Drive Type | Digital |
| Indexing Capability | Yes (Multi-Axis Indexing) |
| Maximum Operating Temperature | 55°C |
| Encoder Feedback Types | Incremental, Sine/Cosine, Intelligent, Absolute |
| Max Encoder Input Frequency (TTL) | 2.5 MHz per channel |
| Max Encoder Input Frequency (Sine/Cosine) | 100 kHz per channel |
| Commutation Startup | Hall Sensor or None |
| Auxiliary Feedback Modes | A Quad B, Step/Direction, CW/CCW |
| Auxiliary Feedback Max Signal Frequency | 2.5 MHz |
| Digital Inputs | 8 Optically Isolated, 12–24VDC, Active High, Current Sinking |
| Digital Outputs | 4 Optically Isolated, 12–24VDC, Active High, Current Sourcing |
| Relay Output | 1 Normally Open, 30VDC Max / 1A Max |
| Analog COMMAND Input | 14-bit A/D, ±10V range |
| Analog ILIMIT Input | 10-bit A/D, 0–10V range |
| Analog Output | 8-bit resolution, ±10VDC range |
| Serial Communication Port | RS-232 / RS-422 / RS-485 |
| Supported Baud Rates | 1200, 2400, 4800, 9600, 19200, 38400 baud |
| Firmware Storage | Field-Programmable Flash Memory |
| Logic Power Supply Input | 12/24VDC (optional external logic power) |
| Absolute Voltage Limits | 207–528V rms (±10% of nominal) |
| Lifecycle Status | Discontinued (as of December 31, 2022) |
| Replacement Product | 2198-E4020-ERS |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
