Product Description
The Ashcroft Type 1005 Commercial Pressure Gauge (15W1005 H 01B 30#) is a 1-1/2" dial analog gauge designed for economical, reliable pressure measurement in a wide range of industrial and OEM applications. It features a black-painted steel case, heat-resistant push-in polycarbonate window, and a Bourdon tube/brass socket wetted path rated to 0–30 PSI. The center back (1/8" NPT) connection and dry-filled design make it suitable for compressors, filter regulators, water pumps, beverage-dispensing equipment, paint sprayers, and similar equipment. The PowerFlex™ movement provides enhanced shock, vibration, and pulsation resistance for reliable performance in demanding environments.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Ashcroft |
| Model / Part Number | 15W1005 H 01B 30# |
| Series / Type | Type 1005 Commercial Pressure Gauge |
| Dial Size | 1-1/2 inch (1.5 in) |
| Pressure Range | 0 – 30 PSI |
| Connection Size | 1/8 in NPT Male |
| Connection Location | Center Back (CBM) |
| Case Material | Black-Painted Steel |
| Window / Lens Material | Polycarbonate (Heat-Resistant Push-In) |
| Socket Material | Brass |
| Bourdon Tube Material | Bronze |
| Dial / Face Material | Aluminum |
| Pointer Material | Aluminum (Black) |
| Movement Type | PowerFlex™ with Polyester Segment |
| Fill Type | Dry (Non-Filled) |
| Accuracy | ±3-2-3% of Span (ASME B40.100 Grade B) |
| Operating Temperature Range | -40°F to 150°F (-40°C to 65°C) |
| Display Type | Analog |
| Scale | Single Scale (PSI) |
| Industry Standard | ASME B40.100, CRN Approved |
| Wetted Parts Material | Brass / Bronze (Copper Alloy) |
| Manufacturer | Ashcroft Inc. |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686208
Mounting Style Center Back Mount (CBM)
Manufacturer Ashcroft
Part Number 15W1005 H 01B 30#
Series Type 1005 Commercial Pressure Gauge
Shelf J-51 Tub 1
Model 15W1005 H 01B 30#
MPN 15W1005 H 01B 30#
Type Pressure Gauge
