Product Description
The Balluff BES00P4 (catalog: BES 516-324-G-E4-C-S49-00,3) is a cylindrical, M8-threaded inductive proximity sensor designed for flush mounting in a wide variety of industrial metal-detection applications. It features a stainless steel housing with a PBT sensing surface, a PNP normally-open switching output, and an IP68 ingress-protection rating, making it suitable for demanding environments including washdown conditions. The sensor connects via a 0.30 m PUR pigtail cable terminated with a 3-pin M8x1 male connector and operates over a broad 10–30 VDC supply range.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Balluff |
| Model / Part Number | BES00P4 |
| Catalog / Long Part Number | BES 516-324-G-E4-C-S49-00,3 |
| Product Series | BES |
| Sensor Type | Inductive Proximity Sensor |
| Principle of Operation | Inductive |
| Body Style | Cylindrical, Threaded Barrel |
| Housing Thread (Style Housing) | M8x1 |
| Overall Dimensions | Ø 8 × 30 mm |
| Mounting / Installation | Flush (shielded) |
| Sensing Range (Rated) | 2 mm |
| Switching Output | PNP, Normally Open (NO) |
| Switching Frequency | 5000 Hz |
| Operating Voltage (Ub) | 10 … 30 VDC |
| Housing Material | Stainless Steel |
| Sensing Surface Material | PBT |
| Connection / Cable | Cable with connector, M8x1-Male, 3-pin, 0.30 m, PUR |
| Number of Pins | 3 |
| Connector Type | M8x1 Male |
| Cable Jacket Material | PUR |
| Ambient Temperature | -40 … +85 °C |
| IP Rating | IP68 |
| Approvals / Conformity | CE, UKCA, cULus, WEEE |
| ECLASS 10.1 / 11.0 | 27-27-01-01 |
| ECLASS 12.0 / 13.0 / 14.0 | 27-27-40-01 |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type PNP Normally Open (NO)
Sensor Type Inductive
Operating Distance 2 mm
Manufacturer Balluff
Part Number BES00P4
Shelf O-6
Model BES00P4
MPN BES00P4
Type Inductive Proximity Sensor
