Product Description
The Hirschmann SSL20-8TX is an industrial unmanaged Ethernet switch designed for reliable networking in industrial environments. This compact switch features 8 Fast Ethernet ports with auto-crossing and auto-negotiation capabilities, housed in an IP30-rated enclosure suitable for DIN rail mounting.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Hirschmann |
| Model/Part Number | SSL20-8TX |
| Full Model Number | SPIDER-SL-20-08T1999999SY9HHHH |
| OEM Part Number | 942132002 |
| Switch Type | Unmanaged |
| Number of Ports | 8 |
| Port Type | 10/100Base-TX RJ45 |
| Network Speed | 10/100 Mbps |
| Operating Voltage | 9.6-32 VDC |
| Nominal Voltage | 12/24 VDC |
| Current Consumption | Max 63 mA at 24V DC |
| Power Consumption | Max 1.5W |
| Operating Temperature | 0°C to +60°C |
| Enclosure Type | IP30 |
| Mounting Type | DIN Rail |
| Weight | 0.35 lbs |
| Features | Auto-crossing, Auto-negotiation, Auto-polarity |
| Series | SPIDER III Standard Line |
| MTBF | 2,218,157 hours (Telcordia) |
| Certifications | UL Certified |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps Max 63 mA at 24V DC
Manufacturer Hirschmann
Enclosure Type IP30
Part Number SSL20-8TX
Shelf K-69
Model SSL20-8TX
MPN SSL20-8TX
Type Network Module
