Product Description
The Mitsubishi SD-Q11 is a non-reversing DC operated magnetic contactor from the MS-N series. This industrial-grade contactor is designed for reliable motor starting and stopping applications with a 24VDC control coil voltage and 9A rated current capacity.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Mitsubishi |
| Model/Part Number | SD-Q11 |
| Series | MS-N |
| Type | Non-Reversing DC Operated |
| Coil Voltage | 24VDC |
| Current Type | DC |
| Rated Current (380-440V) | 9A |
| Number of Poles | 3 |
| Frame Size | 11 |
| Rated Voltage | 690V |
| Rated Capacity (220-240V) | 3 kW |
| Rated Capacity (380-440V) | 4 kW |
| Frequency Range | 50/60 Hz |
| Wiring Type | Screw-Clamp |
| Min Operating Temperature | -10°C |
| Max Operating Temperature | 40°C |
| Standards Compliance | EN60947-4-1 |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686185
Mounting Style DIN Rail/Surface Mount
Current Rating 9A
Country/Region of Manufacture Japan
Material Thermoplastic
Manufacturer Mitsubishi
Part Number SD-Q11
Series MS-N
Shelf C-18
Model SD-Q11
Coil Voltage 24 VDC
Horsepower 4 HP
MPN SD-Q11
Type Contactor
