Product Description
The Motovario 63B/4 is a compact three-phase AC induction motor designed for industrial automation and continuous-duty applications. This motor features IE2 efficiency rating and meets CE and IEC 60034 standards for reliable performance in demanding environments.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Motovario |
| Model/Part Number | 63B/4 |
| Motor Type | AC Induction |
| Power Output | 0.18 kW (0.25 HP) |
| Phase | 3-Phase |
| Poles | 4-Pole |
| Voltage | 230/400V (50Hz), 230/460V (60Hz) |
| Frequency | 50/60 Hz |
| Frame Size | 63 |
| RPM | 1400 (50Hz), 1620-1670 (60Hz) |
| Full Load Amps | 0.67/1.16A (400V/230V at 50Hz) |
| Duty Rating | S1 (Continuous) |
| Efficiency Class | IE2 |
| Protection Degree | IP55 |
| Insulation Class | F |
| Frame Material | Aluminum |
| Cooling Type | IC411 (Self-Ventilated) |
| Shaft Diameter | 11mm |
| Shaft Length | 23mm |
| Operating Temperature | -20°C to +40°C |
| Mounting Type | B3/B5/B14 |
| Weight | 9.26-10.4 lbs |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 0.67A at 400V / 1.16A at 230V
Manufacturer Motovario
Shaft Diameter 11 mm
Enclosure Type TEFC
Part Number 63B/4
Shelf H-4
Model 63B/4
MPN 63B/4
Type AC Motor
