Product Description
The NMB-MAT 4715MS-10T-B50 is a high-performance AC axial cooling fan designed for industrial and commercial cooling applications. This square-frame fan features ball bearing construction for extended life and reliable operation in demanding environments. Manufactured by NMB Technologies (MinebeaMitsumi Group), this fan delivers efficient airflow with low noise operation.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | NMB-MAT |
| Model/Part Number | 4715MS-10T-B50 |
| Manufacturer | NMB Technologies Corporation (MinebeaMitsumi Group) |
| Voltage | 100V AC |
| Power Rating | 15W/14W |
| Current | 0.27A |
| Frequency | 50/60Hz |
| Frame Size | 119mm x 119mm |
| Frame Depth | 38mm |
| Frame Type | Square |
| Bearing Type | Ball Bearing |
| Air Flow (CFM) | 88.3-102.4 CFM |
| Air Flow (m³/min) | 2.5 |
| Static Pressure | 0.26 In H2O / 64.7 Pa |
| Fan Speed | 2600 RPM |
| Noise Level | 37-41 dBA |
| Life Expectancy | 100,000 hours L10 at 25°C |
| Operating Temperature | -20°C to +75°C |
| Weight | 550g |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 0.27 A
Manufacturer Nmb-Mat
Part Number 4715MS-10T-B50
Shelf J-112
Model 4715MS-10T-B50
MPN 4715MS-10T-B50
Type Electric Motor
