Product Description
The PCB Piezotronics Model 307-B is a high-sensitivity, quartz shear ICP® (Integrated Circuit Piezoelectric) single-axis accelerometer designed for precision vibration and shock measurement. It features a 100 mV/g sensitivity, a broad frequency range of 2.5 to 10,000 Hz, a 10-32 top coaxial connector, and ground isolation, making it well-suited for R&D, structural analysis, aerospace, automotive, and industrial test applications. The sensor operates on a constant-current ICP® power source and delivers a low-impedance voltage output compatible with standard data acquisition systems and signal conditioners.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | PCB Piezotronics |
| Model / Part Number | 307-B |
| Product Type | ICP® Accelerometer (Vibration Sensor) |
| Sensing Technology | High Sensitivity Quartz Shear ICP® |
| Sensitivity | 100 mV/g (±10%) |
| Frequency Range | 2.5 Hz to 10,000 Hz (±5%) |
| Measurement Range | ±50 g pk |
| Output Type | ICP® / IEPE Voltage Output (Low Impedance) |
| Connector Type | 10-32 Top Connector |
| Ground Isolation | Yes (Ground Isolated) |
| Number of Axes | Single Axis |
| Supply (Power) | Constant Current ICP® Power Source (2–20 mA typical) |
| Manual Reference | Manual 21354 Rev E (ECN 50523) |
| Manufacturer | PCB Piezotronics, Inc. (An Amphenol Company) |
| Headquarters | Depew, New York, USA |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type ICP® / IEPE Low-Impedance Voltage
Manufacturer Pcb
Part Number 307-B
Shelf K-43
Model 307-B
MPN 307-B
Type Accelerometer
