Product Description
The Phoenix Contact PLC-BPT-24UC/21 (Article No. 2900446) is a 6.2 mm PLC basic terminal block (relay base/socket) from the PLC-INTERFACE product family. It features a push-in connection and is designed for mounting on DIN rail NS 35/7.5, accommodating 1 changeover contact (SPDT) with a nominal input voltage of 24 V AC/DC and a maximum current rating of 6 A. This base block is sold without a relay or solid-state relay and requires a compatible plug-in miniature relay for operation.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Phoenix Contact |
| Model / Part Number | PLC-BPT-24UC/21 |
| Article Number | 2900446 |
| Product Type | Relay Base / Relay Socket |
| Product Family | PLC-INTERFACE |
| Nominal Input Voltage | 24 V AC/DC |
| Number of Changeover Contacts | 1 |
| Connection Method | Push-in connection |
| Stripping Length | 10 mm |
| Conductor Cross Section (Rigid) | 0.14 mm² ... 2.5 mm² |
| Conductor Cross Section (Flexible) | 0.14 mm² ... 2.5 mm² |
| Conductor Cross Section (Single Ferrule) | 0.2 mm² ... 2.5 mm² |
| Conductor Cross Section (TWIN Ferrule) | 2x 0.5 mm² ... 1 mm² |
| Conductor Cross Section (AWG) | 26 ... 14 AWG |
| Protective Circuit | Bridge rectifier |
| Status Display | LED |
| Mounting Type | DIN Rail NS 35/7.5 |
| Mounting Position | Any |
| Assembly Note | In rows with zero spacing |
| Operating Mode | 100% operating factor |
| Overvoltage Category | II |
| Pollution Degree | 3 |
| Width | 6.2 mm |
| Height | 80 mm |
| Depth | 94 mm |
| Color | Gray (RAL 7042) |
| Flammability Rating (UL 94) | V0 (Housing) |
| Ambient Temperature (Operation) | -40 °C ... 60 °C |
| Ambient Temperature (Storage/Transport) | -40 °C ... 85 °C |
| Number of Pins | 5 |
| Application Standards | IEC/EN 60664-1 |
| EMC Classification | Class A |
| Approvals / Certifications | CE, UKCA, cULus Recognized, UL Recognized, DNV GL, EAC, Shipbuilding (TAE0000196) |
| Packing Unit | 10 pc |
| Application | Universal |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Mounting Style DIN Rail
Current Rating 6 A
Country/Region of Manufacture Germany
Manufacturer Phoenix Contact
Part Number PLC-BPT-24UC/21
Shelf F-19 Tub
Model PLC-BPT-24UC/21
Coil Voltage 24V AC/DC
MPN PLC-BPT-24UC/21
Type Relay
