Product Description
The phytron ZMP 92/70 H/V is a stepper motor drive card (power stage board) designed for bipolar control of two-phase stepper motors. It operates using phytron's patented SYNCHROCHOP principle, which regulates motor current for both phases synchronized with the rotating field, reducing resonance and motor noise during operation. This unit is rated at up to 9.2 A peak phase current at 70 V motor voltage and is now discontinued by the manufacturer.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | phytron |
| Model / Part Number | ZMP 92/70 H/V |
| Product Type | Stepper Motor Drive Card (Power Stage Board) |
| Peak Phase Current | 9.2 A (9 A peak) |
| Motor Voltage | 70 V |
| Mains / Input Voltage | 230 V AC ±10%, 50–60 Hz (115 V AC option) |
| Motor Type Supported | 2-phase stepper motors (bipolar) |
| Motor Lead Configurations | 4-lead, 6-lead, or 8-lead |
| Step Resolutions Supported | Full step, Half step, 1/2.5 step, 1/5 step |
| Current Regulation Technology | SYNCHROCHOP (patented phytron principle) |
| Current Setting Increments | 16 programmable increments |
| Variant / Suffix | H/V (High Voltage) |
| Also Known As / Related PN | ZMP-MINI-92-70, ZMP92/70, STEMAK 02003819 |
| Board Dimensions (approx.) | 180 × 100 × 20 mm |
| Weight (approx.) | 0.3 kg |
| Status | Discontinued by Manufacturer |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 9.2A peak
Manufacturer Phytron
Part Number ZMP 92/70 H/V
Shelf K-48
Input Voltage 230V AC ±10%, 50-60 Hz (115V AC option)
Model ZMP 92/70 H/V
MPN ZMP 92/70 H/V
Type Stepper Drive
