Product Description
The Rexnord HP8505-3.25 MTW is an 8500 Series Molded-to-Width (MTW) MatTop® conveyor chain designed for straight-running applications. It features a solid top surface molded in Brown High Performance (HP) material and assembled with polyester pins, making it suitable for conveying individual units as well as packaged and cased goods. The chain is FDA-compliant for direct food contact per FDA 21 CFR § 177.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Rexnord |
| Model / Part Number | HP8505-3.25 MTW Chain |
| Manufacturer Part Number (MPN) | 10028434 |
| Catalog / SKU Number | 81418511 |
| Series | 8500 Series MatTop |
| Chain Type | Molded-to-Width (MTW) MatTop® Chain |
| Running Style | Straight Running |
| Surface Type | Solid Top |
| Chain Width | 3.25 in (82.55 mm) |
| Chain Pitch | 0.75 in (19.1 mm) |
| Chain Height (Thickness) | 0.34 in (8.6 mm) |
| Chain Strength | 625 lb (2775 N) |
| Chain Material | Brown High Performance (HP) |
| Pin / Rod Material | Polyester |
| Min. Backflex Radius | 1.00 in (25.4 mm) |
| Open Area | 4.1% |
| Standard Length | 10 ft (3.048 m) / 160 pitches |
| FDA Compliance | FDA 21 CFR § 177 (Direct Food Contact) |
| PosiTrack | No (Standard MTW — no PosiTrack) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Rexnord
Part Number HP8505-3.25 MTW CHAIN
Shelf K-24
Model HP8505-3.25 MTW CHAIN
MPN HP8505-3.25 MTW CHAIN
Type Conveyor Chain
