Product Description
The Bosch Rexroth 0608701016 is an EC302 SZ2 brushless EC (electronically commutated) Nutrunner belonging to the Rexroth Tightening System 300 Series. It is specifically engineered for use in EC tightening spindles (Size 2), providing precise, controlled torque delivery for automated screw-fastening applications in industrial assembly lines. The motor features a 14-pin connector interface, operates on a 0–230V AC three-phase variable-speed supply, achieves a maximum speed of 20,000 RPM, and is rated at 160W (0.16 kW) with an IP54 ingress protection rating. It is maintenance-free for 1 million full load cycles and carries an Insulation Class F rating.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Bosch Rexroth |
| Model / Part Number | 0608701016 |
| Model Code | EC302 SZ2 |
| Product Series | System 300 |
| Motor Type | EC Motor (Electronically Commutated / Brushless) |
| Rated Voltage | 0–230 VAC (3-phase) |
| Maximum Current | 0.7 A |
| Torque Constant | 0.1 Nm/A |
| Rated Torque | 0.6 Nm |
| Peak Torque | 0.7 Nm |
| Maximum Speed | 20,000 RPM |
| Connector / Pins | 14-Pin |
| Tightening Spindle Size | Size 2 (EC, Working Range 0.6–2.5 Nm) |
| Installation Length | 65.5 mm |
| Weight | 0.4 kg |
| Phase | 3-Phase |
| Application | EC Tightening Spindle / Automated Assembly Screwdriving |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Stall Torque 0.07 Nm
Country/Region of Manufacture Germany
Full Load Amps 0.7A
Manufacturer Rexroth
Part Number 0608701016
Shelf A-12
Model 0608701016
MPN 0608701016
Type Nutrunner
