Product Description
The SATO M-8485Se is an industrial-grade OEM print engine designed to be integrated into high-performance on-site automatic print-and-apply labeling systems. Based on the popular M-8485S, the M-8485Se is the industry's first "Plug and Play" printer capable of full high-speed bi-directional communications. Utilizing the latest in 32-bit microprocessor technology, along with 16 MB of standard RAM, the M8485Se provides virtually instantaneous "time to first label out". Designed with a modular interface slot, the M8485Se allows for a wide variety of interface options to be easily installed and field upgraded.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Sato |
| Model / Part Number | M-8485Se |
| Product Series | M84Se Series |
| Product Type | Industrial OEM Barcode Print Engine |
| Print Method | Direct Thermal / Thermal Transfer |
| Print Resolution | 203 dpi (203 x 203 dpi) |
| Maximum Print Speed | 12 ips (300 mm/s) — User Selectable 4–12 ips |
| Maximum Print Width | 5.0 inches |
| Label Width Range | 1 inch to 5.25 inches |
| Label Length Range (Internal Memory) | 0.25 inches to 14 inches |
| Label Length Range (PCMCIA Card) | Up to 49.2 inches |
| Standard RAM | 16 MB |
| Standard Flash ROM | 2 MB |
| Input Voltage | 100–120 / 200–240 VAC |
| Frequency | 50/60 Hz |
| Current Draw | 7A @ 100–120V / 3.5A @ 200–240V |
| Label Sensor Types | Label Gap (Transmissive) and Eye-Mark (Reflective) |
| Processor | 32-bit RISC Microprocessor |
| Printer Command Language | SBPL v4.2 (SATO Barcode Printer Language) |
| Available Interfaces | IEEE-1284 Parallel, Serial (RS-232C / RS-422 / RS-485), USB, Ethernet (10/100BaseTx) |
| Label Feed Direction | Left-to-Right (Standard) or Right-to-Left (Opposite/Left-Hand) |
| Graphics Support | SATO Hex/Binary, .BMP, .PCX — Full dot addressable |
| Real Time Clock | Yes — Date/Time stamp on labels |
| Form Overlay | Yes — High-speed editing of complex label formats |
| Optional Memory Expansion | PCMCIA Cards up to 16MB Flash or 4MB SRAM; 8MB Flash ROM |
| EMI/RFI Compliance | FCC Class B, EN55022 Class B, EN61000 |
| Status | Discontinued by Manufacturer |
| Replacement Model | S84-ex Series (released 2015) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 7A (100–120V) / 3.5A (200–240V)
Manufacturer SATO
Part Number M-8485SE
Series M84Se
Shelf K-59
Model M-8485SE
MPN M-8485SE
Type Barcode Scanner
