Product Description
The SensoPart FR 20 RG-PSM4 is a compact rectangular photoelectric sensor from the F20 series, designed for autocollimation-based glass detection applications. It features Teach-In adjustment, a PNP normally-open switching output, and connects via an M8 4-pin plug connector. The sensor is part of SensoPart's widely-used F20 miniature housing series, offering a broad range of detection variants suited for positioning, transparent object detection, and fine-part sensing in industrial automation environments.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Sensopart |
| Model / Part Number | FR 20 RG-PSM4 |
| Product Type | Photoelectric Sensor |
| Series | F20 (32 x 20 x 12 mm housing) |
| Sensing / Operating Range | 500 mm |
| Detection Method | Autocollimation (Glass Detection) |
| Adjustment | Teach-In |
| Light Source | LED, Red |
| Output Type | PNP N.O. (Normally Open) |
| Supply Voltage | 10–30 V DC |
| Switching Frequency | 1000 Hz |
| Connection Type | Plug M8, 4-pin |
| Housing Dimensions | 32 x 20 x 12 mm |
| Enclosure Rating | IP 67 |
| Operating Temperature | -20°C to +60°C |
| Application | Glass Detection, Transparent Object Detection |
| Status | Discontinued by Manufacturer |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type PNP
Sensor Type Photoelectric
Operating Distance 500 mm
Manufacturer Sensopart
Enclosure Type IP67
Part Number FR 20 RG-PSM4
Shelf Q-9
Model FR 20 RG-PSM4
MPN FR 20 RG-PSM4
Type Photoelectric Sensor
