Product Description
The Sick DSL-1205-GOM6C (part no. 6025930) is a double-ended sensor connection cable featuring M12 female straight to M12 male straight connectors, both 5-pin A-coded, with a 0.6-meter unshielded PUR halogen-free cable. It is designed for use in industrial sensor wiring applications, particularly for drag-chain (cable carrier) installations, and is compatible with SICK sensors and actuators using the standard M12, 5-pin A-coded interface. This product has been discontinued by SICK; successor products are available through SICK's official channels.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Sick |
| Model / Part Number | DSL-1205-GOM6C |
| SICK Part No. | 6025930 |
| Product Family | DSL-1205 Series |
| Product Category | Connectors and Cables / Sensor Connection Cable |
| Connection Type Head A | Female connector, M12, 5-pin, straight, A-coded |
| Connection Type Head B | Male connector, M12, 5-pin, straight, A-coded |
| Number of Pins | 5 |
| Connector Coding | A-coded |
| Cable Length | 0.6 m |
| Number of Wires | 5-wire |
| Jacket Material | PUR (Polyurethane), halogen-free |
| Jacket Color | Black |
| Cable Diameter | 5 mm |
| Conductor Cross Section | 0.34 mm² |
| Shielding | Unshielded |
| Connector Material | TPU |
| Connector Color | Black |
| Locking Nut Material | Zinc die-cast, nickel-plated |
| Tightening Torque | 0.4 Nm |
| Reference Voltage | ≤ 60 V |
| Current Loading | 4 A |
| Bending Radius – Flexible Use | > 10 × cable diameter |
| Bending Radius – Stationary | > 5 × cable diameter |
| Bending Cycles | ≥ 4,000,000 |
| Application / Suitability | Drag chain (cable carrier) use |
| Halogen-Free | Yes |
| Product Status | Discontinued |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686208
Full Load Amps 4 A
Manufacturer SICK
Part Number DSL-1205-GOM6C
Shelf P-7
Model DSL-1205-GOM6C
MPN DSL-1205-GOM6C
Type Sensor Cable
