Product Description
The Simco-Ion D167QG (catalog number 4000076) is a high-voltage static eliminator power supply designed to power Type HS Shockless Ionizing Air Nozzles in industrial static control applications. It accepts 120VAC input and delivers a 7 kV RMS high-voltage output to energize ionizing nozzle systems that eliminate or significantly reduce electrostatic charges on materials, webs, and parts during manufacturing. The unit is environmentally potted with no replaceable parts and features built-in short-circuit protection requiring no external fuse.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Simco-Ion (ITW Simco-Ion) |
| Model / Part Number | D167QG |
| Catalog / Item Number | 4000076 |
| Product Type | Static Eliminator Power Supply (Power Unit) |
| Series | D Series |
| Color | Gray |
| Form Factor | Compact Panel/Wall Mount |
| Input Voltage | 120VAC |
| Input Current | 0.25 A (Maximum) |
| Input Frequency | 50/60 Hz |
| Maximum Power | 30 W |
| Output Voltage | 7 kV RMS |
| Number of Outlets | 1 |
| Connectors | AC Line Cord Input (NEMA 5-15P), Spring-Loaded High Voltage Output Connector |
| Cooling | Passive (No Fan, Environmentally Potted) |
| Short-Circuit Protection | Yes (no fuse required) |
| Construction | Environmentally potted, no replaceable parts |
| Compatible Equipment | Type HS Shockless Ionizing Air Nozzles (up to 100 in series), MEB Shockless Static Bars, MEJ Shockless Static Bars, Shockless Static Bars with Shielded Cable |
| Application | Industrial static charge elimination / neutralization |
| Approvals | UL, CSA, FM |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Simco
Part Number D167QG
Shelf F-10
Model D167QG
MPN D167QG
Type Power Supply
