Product Description
The Sipco TechnoGear N080D020-15CQ-B8O0-XX-S-0 is a precision inline planetary gear reducer designed for servo drive systems requiring high positioning accuracy and reliable torque transmission. This unit features an 80mm IEC flange frame, a 20:1 reduction ratio, keyless clamping input coupling, and synthetic lubrication for maintenance-reduced operation. It is part of SIPCO's TechnoGear planetary reducer series, engineered for low backlash and high dynamic loading in compact, modular packages suitable for robotics, packaging, and motion control applications.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Sipco |
| Model / Part Number | N080D020-15CQ-B8O0-XX-S-0 |
| Product Line | TechnoGear |
| Product Type | Planetary Gear Reducer |
| Gear Ratio | 20:1 |
| Configuration | In-Line (Concentric Shaft) |
| Number of Stages | 2 (Double Stage) |
| Frame / Flange Size | 80mm |
| Output Shaft Diameter | 20mm |
| Input Shaft Diameter | 14mm |
| Input Style | Keyless Clamping Coupling (CQ) |
| Motor Adapter Flange | IEC B8 / 80mm Servo Flange |
| Backlash Class | Standard (≤15 arc-minutes) |
| Mounting Type | Flange Mount |
| Lubrication | Synthetic (Lubricated for Life) |
| Efficiency | 90–96% |
| Max Input Speed | Up to 6,000 RPM |
| Special Options | None (XX) |
| Version | Standard (S) |
| Manufacturer | Sipco / SIPCO-MLS |
| Typical Applications | Robotics, Packaging, CNC, Servo Drives, Motion Control |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Sipco
Part Number N080D020-15CQ-B8O0-XX-S-0
Shelf H-6
Model N080D020-15CQ-B8O0-XX-S-0
MPN N080D020-15CQ-B8O0-XX-S-0
Type Gear Reducer
