Product Description
The SMC CLQ Series Compact Cylinder with Lock offers drop prevention when the pressure of air source is decreased or residual pressure is released, enabling locking at any position within the entire stroke. The CLQ has a low profile design with a compact lock unit. This 80mm bore pneumatic cylinder is designed for industrial automation applications requiring precise positioning control.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SMC |
| Model/Part Number | CDLQB80-40D-B-F7BVL |
| Series | CLQ Compact Cylinder With Lock |
| Cylinder Type | Compact Cylinder with Lock |
| Bore Diameter | 80mm |
| Stroke Length | 40mm (estimated from part number) |
| Action | Double Acting Single Rod |
| Mounting Type | Through Hole Type |
| Auto Switch | F7BVL Configuration |
| Maximum Operating Pressure | 1.0 MPa |
| Minimum Operating Pressure | 0.2 MPa |
| Proof Pressure | 1.5 MPa |
| Operating Temperature | -10 to 60°C (with auto switch) |
| Piston Speed | 50 to 500mm/s |
| Port Size | Rc 1/4 |
| Locking Function | Extension and Retraction Locking |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer SMC
Part Number CDLQB80-40D-B-F7BVL
Shelf B-2
Bore Diameter 80 mm
Model CDLQB80-40D-B-F7BVL
MPN CDLQB80-40D-B-F7BVL
Type Pneumatic Cylinder
