Product Description
The Togi PCN-4F40 is a 40-pole interface terminal block designed to connect between PLCs and field devices. It features a screw terminal connection system with FCN connector compatibility and supports both DIN rail and direct mounting configurations.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Togi |
| Model/Part Number | PCN-4F40 |
| Product Type | Interface Terminal Block |
| Series | PCN |
| Number of Poles | 40 |
| Connection Type | Screw Terminal (Sems Screw) |
| Connector Type | FCN |
| Pitch | 7.62mm |
| Rated Voltage | 125V |
| Rated Current | 1A |
| Operating Temperature | -10°C to +50°C |
| Cable Size | 1.25mm |
| Mounting Type | DIN Rail/Direct Mounting |
| Terminal Method | Embedded Screw (Y Terminal) |
| Material | PPO |
| Width | 40mm |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Togi
Part Number PCN-4F40
Shelf E-8 Tub 5
Model PCN-4F40
MPN PCN-4F40
Type Interface Terminal Block
