Product Description
The Arrow Hart (Eaton) AH430P7W is an IEC 60309 watertight pin and sleeve plug rated for 30 amperes at 480V AC, three-phase service. Constructed from rugged nylon with nickel-plated brass contacts, this male plug provides IP69K-rated protection against high-pressure, high-temperature washdown environments. It accepts #10–#2 AWG back-wire conductors and is designed for secure mating with compatible IEC 309 receptacles and connectors in demanding industrial wet locations.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Arrow Hart (Eaton) |
| Model / Part Number | AH430P7W |
| Product Type | IEC 60309 Pin & Sleeve Plug (Male) |
| Amperage | 30A |
| Voltage | 480V AC |
| Phase | 3-Phase |
| Number of Poles | 3-Pole |
| Number of Wires | 4-Wire (with Grounding) |
| Gender | Male (Plug) |
| IP Rating (Watertight) | IP69K (also IP67) |
| Wire Range (AWG) | #10–#2 AWG |
| Cable Entry Diameter Range | 0.433–0.985 in (1.10–2.50 cm) |
| Wiring Method | Back Wire |
| Horsepower Rating | 10 HP |
| Color | Red |
| Body Material | Nylon |
| Contact Material | Nickel Plated Brass |
| Standard | IEC 60309 (IEC 309) |
| Clock Position (Ground) | 7 Hour |
| Series | IEC 309 Watertight |
| Certifications | cRUus |
| Product Length / Depth | 10.375 in |
| Product Height | 4.813 in |
| Product Width | 4.75 in |
| Product Weight | 0.997 lb |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Full Load Amps 30A
Manufacturer Arrow/hart
Enclosure Type Watertight
Part Number AH430P7W
Shelf K-66
Model AH430P7W
MPN AH430P7W
Type Disconnect
