Product Description
The Dodge TL30H100-2012 is a Dyna-Sync Type KF1 timing belt pulley designed for synchronized, no-slip power transmission applications. It features a Taper-Lock bore that accepts a 2012-series bushing (sold separately), accommodating shaft diameters from 1/2 in to 2-1/8 in. The pulley is constructed from ductile iron with a black oxide finish and flanged steel flanges, providing reliable, low-maintenance performance with virtually no backlash.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Dodge |
| Model / Part Number | TL30H100-2012 |
| Manufacturer Part Number (MPN) | 113620 |
| Product Type | Timing Pulley (Dyna-Sync Sprocket) |
| Series / Style | Dyna-Sync Type KF1 |
| Number of Teeth (Grooves) | 30 |
| Belt Pitch | 1/2 in (H-Series) |
| Belt Width | 1 in (1.062 in usable) |
| Outside Diameter | 5.02 in |
| Pitch Diameter | 4.775 in |
| Flange Diameter | 5.02 in |
| Face Width | 1.32 in |
| Hub Projection | 0.06 in |
| Bore Type | Taper-Lock (requires 2012 bushing) |
| Bore Diameter Range | 1/2 in to 2-1/8 in |
| Required Bushing | 2012 Taper-Lock |
| Material | Ductile Iron |
| Flange Material | Steel |
| Finish | Black Oxide |
| Hub Configuration | Taper-Lock Hub |
| Drive Efficiency | ~98% |
| Drive Ratio | 8.5:1 |
| Lubrication Required | No |
| Weight | 4.33 lb |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Dodge
Part Number TL30H100-2012
Shelf D-11
Model TL30H100-2012
MPN TL30H100-2012
Type Timing Pulley
