Product Description
The Fanuc A05B-2650-J380 is a 7-meter (7M) camera connection cable designed for use with Fanuc R-30iB and R-30iB Mate robot controllers as part of the iRVision integrated vision system. This cable routes the analog camera signal from the Main PCB (JRL7 port) directly to an external camera such as the Sony XC-56, eliminating the need for a separate vision CPU board. It features a "D"-shaped connector on the controller end and a round connector on the camera end, enabling direct camera-to-controller connectivity for 2D vision guidance applications. The cable carries an EIA RS-170 analog video signal, ensuring compatibility with standard analog cameras used in Fanuc iRVision setups.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Fanuc |
| Model / Part Number | A05B-2650-J380 |
| Description | 7M CAM CBL MAIN PCB→CAM (7-Meter Camera Cable, Main PCB to Camera) |
| Cable Length | 7 Meters (7M) |
| Cable Function | Camera Connection – Main PCB to Analog Camera |
| Controller End Connector | JRL7 Port ("D"-shaped connector) |
| Camera End Connector | Round Connector |
| Compatible Camera | Sony XC-56 Analog Camera (and compatible analog cameras) |
| Compatible Controllers | Fanuc R-30iB, R-30iB Mate |
| Vision System | Fanuc iRVision (Integrated Robot Vision) |
| Signal Type | Analog Camera Signal |
| Product Series | A05B-2650 (R-30iB Mate Accessories) |
| Connection Route | Direct PCB to Camera (no multiplexer required) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Fanuc
Part Number A05B-2650-J380
Controller Platform R-30iB / R-30iB Mate
Shelf K-20
Model A05B-2650-J380
MPN A05B-2650-J380
Type Communication Module
