Product Description
The Hoffman A-8064CHNFSS is a NEMA Type 4X stainless steel junction box enclosure designed for use in indoor or outdoor and corrosive environments. It features Type 304 stainless steel construction with a rugged continuous hinge, seamless foam-in-place gasket, and stainless steel screw-down clamps that provide a reliable watertight and dusttight seal. The enclosure measures 8 inches high × 6 inches wide × 4 inches deep, with a 14-gauge body and 16-gauge door, and carries UL, cUL, and CSA certifications along with an IP66 rating.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Hoffman (nVent Hoffman) |
| Model / Part Number | A-8064CHNFSS |
| Product Type | Junction Box / Electrical Enclosure |
| NEMA Rating | Type 3R, 4, 4X, 12, 13 |
| IP Rating | IP66 |
| Height (Interior Nominal) | 8 in / 203 mm |
| Width (Interior Nominal) | 6 in / 152 mm |
| Depth | 4 in / 102 mm |
| Overall Exterior Dimensions | 9.50 x 6.94 in / 241 x 176 mm |
| Interior Panel Size | 6.75 x 4.88 in / 171 x 124 mm |
| Material | Type 304 Stainless Steel |
| Body Gauge | 14 Gauge (1.98 mm) |
| Cover / Door Gauge | 16 Gauge |
| Finish | #4 Brushed Stainless Steel |
| Cover / Hinge Type | Continuous Hinge with Removable Pin |
| Latch / Closure Type | Stainless Steel Screw-Down Clamps |
| Gasket Type | Seamless Foam-In-Place |
| Mounting Type | Wall Mount (Surface) |
| Mounting Footprint | 8.75 x 4.00 in / 222 x 102 mm |
| Number of Doors | 1 |
| Service Type | Indoor / Outdoor |
| Compatible Steel Back Panel | A8P6 |
| Compatible Galvanized Panel | A8P6G |
| Bulletin Number | A51S |
| UL Certification | UL 50, UL 50E Listed; File No. E27567 |
| UL 508A Listed | File No. E61997 |
| CSA Certification | cUL Listed per CSA C22.2 No. 94 |
| Applicable Standard | IEC 60529 |
| RoHS Compliant | Yes |
| Weight | 5.4 lbs (2.4 kg) |
| UNSPSC | 39121303 |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Country/Region of Manufacture USA
Dimensions 9.50 x 6.94 in / 241 x 176 mm
Material Type 304 Stainless Steel
Mount 8.75 x 4.00 in / 222 x 102 mm
Manufacturer Hoffman
Cable IEC 60529
Empty Weight 5.4 lbs (2.4 kg)
Enclosure Type Type 3R, 4, 4X, 12, 13
Part Number A-8064CHNFSS
Series A51S
Shelf I-17
Model A-8064CHNFSS
MPN A-8064CHNFSS
Type Electrical Enclosure
