Product Description
The Mitsubishi Electric Q01UCPU is a Universal Model QCPU module belonging to the MELSEC-Q Series (QnU sub-range) of modular programmable logic controllers. It provides 15K steps (60KB) of program memory, supports up to 1024 local I/O points (8192 local + remote), and features both USB (Mini-B) and RS-232 communication ports for programming and connectivity. The module is powered via a dedicated Q-Series power supply unit at 5V DC and mounts into standard Q-Series backplane racks.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | MITSUBISHI ELECTRIC |
| Model / Part Number | Q01UCPU |
| Series | MELSEC-Q (QnU / Universal Model QCPU) |
| Controller Platform | MELSEC-Q |
| Product Type | Universal PLC CPU Module |
| Control Method | Stored program cyclic operation (Refresh mode) |
| Program Memory (Drive 0) | 15K steps / 60KB |
| Standard RAM (Drive 3) | 60KB |
| Standard ROM (Drive 4) | 128KB |
| CPU Shared Memory | 8KB |
| Total Memory | 32 MB |
| Local I/O Points | 1024 points (X/Y0 to 3FF) |
| Local + Remote I/O Points | 8192 points |
| Processing Speed (LD instruction) | 60 ns |
| Processing Speed (MOV instruction) | 120 ns |
| Processing Speed (PC MIX) | 9.79 μs |
| Floating Point Addition | 240 ns |
| Constant Scan Setting | 0.5 to 2000 ms (in 0.5 ms increments) |
| Programming Languages | Relay Symbol (LD), Logic Symbolic, MELSAP3 (SFC), MELSAP-L, Function Block (FBD), Structured Text (ST) |
| Internal Relays (M) | 8192 points (default, changeable) |
| Latch Relays (L) | 8192 points (default, changeable) |
| Timers | 2048 points |
| Counters | 1024 points |
| Data Registers (D) | 12288 points |
| Link Relays (B) | 8192 points |
| Link Registers (W) | 8192 points |
| Annunciator (F) | 2048 points |
| Edge Relays (V) | 2048 points |
| File Registers | 65536 points |
| Communication Ports | USB (Mini-B) × 1, RS-232 (9-pin D-Sub female) × 1 |
| Supply Voltage | 5V DC (from dedicated Q-Series power supply unit) |
| Internal Current Consumption | 0.33 A (at 5V DC) |
| Battery Backup | Yes (buffer battery included) |
| Mounting Type | Rack / Backplane (Q-Series base unit) |
| Slots Occupied | 1 |
| Width | 27.4 mm |
| Height | 98 mm |
| Depth | 89.3 mm |
| Weight | 0.15 kg |
| Operating Temperature | 0°C to +55°C (32°F to 131°F) |
| Compliance / Certifications | UL, cUL, CE, RoHS |
| Compatible System | MELSEC-Q Series (Q-Series base units, I/O, and intelligent function modules) |
