Product Description
The Mitsubishi Electric FR-A044-1.5K-UL is a 1.5 kW (2 HP) Variable Frequency Drive (VFD) from the FR-A044 series, designed for demanding industrial motor control applications in the North American market (UL-listed). It accepts 3-phase 380–460V AC input and delivers precisely controlled 3-phase output across a wide frequency range of 0.2–400 Hz, utilizing magnetic flux vector control for high starting torque and stable low-speed operation. This unit is a discontinued legacy product (discontinued 2008); the Mitsubishi FR-E800 series is the manufacturer-recommended replacement.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Mitsubishi Electric |
| Model / Part Number | FR-A044-1.5K-UL |
| Alternate Part Number | FRA04415KUL |
| Product Series | FR-A044 (A024/A044) |
| Product Type | Variable Frequency Drive (VFD) / Inverter |
| Rated Power | 1.5 kW (2 HP) |
| Input Voltage | 380–460V AC |
| Input Phase | 3-Phase |
| Input Frequency | 50/60 Hz |
| Input Current (Rated) | 6.9 A |
| Output Voltage | 3-Phase, Max 380–460V AC |
| Output Current (Rated) | 4 A |
| Output Frequency Range | 0.2–400 Hz |
| Output Horsepower | 2 HP |
| Control Method | Magnetic Flux Vector Control |
| Starting Torque | 200–300% (at low speed) |
| Torque Type | Constant Torque (CT) |
| Enclosure Type | IP20 |
| Dimensions (H × W × D) | 200 × 150 × 143 mm (7.87 × 5.91 × 5.63 in) |
| Weight | 2.355 kg (5.19 lbs) |
| Certification | UL Listed |
| Stall Prevention | Selectable (Tripless Function) |
| Lifecycle Status | Discontinued (2008) |
| Recommended Replacement | Mitsubishi FR-E800 Series |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686208
Manufacturer Mitsubishi
Enclosure Type IP20
Part Number FR-A044-1.5K-UL
Shelf E-19
Input Voltage 380-460 VAC
Model FR-A044-1.5K-UL
MPN FR-A044-1.5K-UL
Type VFD
