Product Description
The Rhino PSC-24-015 is a compact switching power supply designed for industrial applications requiring reliable 24VDC power. This unit features adjustable DC output, universal AC input voltage, and integrated DIN rail mounting for easy installation in control panels.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Rhino |
| Model/Part Number | PSC-24-015 |
| Type | Switching Power Supply |
| Series | PSC |
| Output Voltage | 24.0 VDC |
| Output Current | 0.63 A |
| Output Power | 15 W |
| Output Voltage Range (Adjustable) | 24.0 to 28.0 VDC |
| Input Voltage (Nominal) | 100-240 VAC |
| Input Voltage Range (Universal) | 85-264 VAC |
| Input Frequency | 47-63 Hz |
| Phase | 1-Phase |
| Efficiency | 83% |
| Mounting Type | 35mm DIN Rail Mount |
| Enclosure Type | Enclosed Plastic Housing |
| Terminal Type | Screw Terminals |
| Safety Class | NEC Class 2 |
| Width | 26.3 mm (1.04 inches) |
| Weight | 3.53 oz (100 g) |
| Protection Class | Class II to IEC/EN 60536 |
| IP Rating | IP20 |
| Features | DC-OK LED Indication, Adjustable Output, Current Limitation |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Rhino
Enclosure Type Enclosed Plastic Housing
Part Number PSC-24-015
Shelf K-46
Model PSC-24-015
MPN PSC-24-015
Type Switching Power Supply
