Product Description
The SMC HHB-142396 is a custom-built pneumatic valve manifold assembly produced by H.H. Barnum Company, an authorized SMC distributor. HHB-prefixed part numbers represent proprietary custom assemblies built to end-user specifications using SMC pneumatic valve and manifold components. Because these assemblies are made to order and assigned a unique H.H. Barnum internal item number, detailed configuration specifications (number of stations, valve series, coil voltage, port size) must be confirmed by inspecting the physical unit's label and component markings.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SMC |
| Model / Part Number | HHB-142396 |
| Product Type | Pneumatic Valve Manifold Assembly |
| Manufacturer | SMC Corporation of America |
| Assembled By | H.H. Barnum Company (Authorized SMC Distributor) |
| Assembly Type | Custom / Made-to-Order (Proprietary HHB Assembly Number) |
| Operation | Solenoid |
| Valve Ways & Position | 5/2-Way |
| Fluid Medium | Air (Pneumatic) |
| Application | Factory Automation / Directional Control |
| Number of Stations | See unit label |
| Valve Series | See unit label (SY, VQC, or SX series typical) |
| Coil Voltage | See unit label |
| Port Size | See unit label |
| Electrical Connection | See unit label |
| Configuration Notes | Custom assembly — inspect physical unit for full configuration |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Country/Region of Manufacture Japan
Max. Fluid Pressure Air
Application Factory Automation / Directional Control
Manufacturer SMC
Part Number HHB-142396
Series See unit label
Shelf A-9
Model HHB-142396
Port Size See unit label
Coil Voltage See unit label
MPN HHB-142396
Type Manifold
