Product Description
The SMC NCQ2B40-25D is a compact pneumatic cylinder from the NCQ2/CQ2 Series, featuring a 40 mm bore and 25 mm stroke in a space-saving, through-hole mountable body. It operates as a double-acting, single-rod cylinder with a standard body and standard piston rod, designed for North American RC/M port threading. This is a legacy product superseded by the NCQ2B40-25DZ, and is valued for its lightweight aluminum alloy construction and versatile auto-switch groove compatibility.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SMC |
| Model / Part Number | NCQ2B40-25D |
| Series | NCQ2 / CQ2 |
| Product Type | Compact Cylinder |
| Cylinder Action | Double Acting |
| Rod Type | Single Rod (Standard) |
| Bore Diameter | 40 mm |
| Stroke Length | 25 mm |
| Maximum Operating Pressure | 1.0 MPa (145 PSI) |
| Minimum Operating Pressure | 0.05 MPa (7.25 PSI) |
| Proof Pressure | 1.5 MPa (215 PSI) |
| Port Thread Type | RC/M Thread (North American) |
| Port Size | Rc 1/8 |
| Mounting Style | Through-Hole (Standard) |
| Built-in Magnet | Without Magnet |
| Body Type | Standard Body |
| Rod End Thread | Female Thread (Standard Body Option) |
| Fluid | Compressed Air |
| Piston Speed | 50 to 1000 mm/s |
| Operating Temperature Range | -10 to 70°C (14 to 158°F) |
| Cushion Type | Rubber Bumper |
| Cylinder Tube Material | Aluminum Alloy |
| Piston Rod Material | Stainless Steel |
| Piston Material | Aluminum Alloy |
| Auto Switch Mounting Grooves | 4 Sides (ø32–ø100) |
| Auto Switch Included | Without Auto Switch |
| Approximate Weight | 0.63 lbs (286 g) |
| Legacy / Replacement | Legacy product — replaced by NCQ2B40-25DZ |
