Product Description
The Sonics & Materials U-B2224 is an ultrasonic welding booster designed as a stack component for ultrasonic plastics assembly systems. The booster is interposed between the converter (transducer) and the horn (sonotrode) within the ultrasonic stack, serving to transform and transmit vibratory amplitude from the converter to the welding horn. Sonics & Materials, Inc. is a leading manufacturer of ultrasonic plastics and metal welding systems, offering stack components including boosters, converters, and horns matched to their ultrasonic power supplies across frequencies of 20, 30, 35, and 40 kHz.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Sonics |
| Model / Part Number | U-B2224 |
| Manufacturer | Sonics & Materials, Inc. |
| Product Type | Ultrasonic Booster |
| Frequency | 20 kHz (inferred from part number) |
| Gain Ratio | 2:1 (inferred from part number) |
| Component Role | Stack component between converter and horn |
| Compatible Systems | Sonics E, F, and G Series ultrasonic welding presses (verify) |
| Material | Titanium or Aluminum (verify against label) |
| Mount Type | See label / verify |
| Thread Size (Input/Output) | See label / verify |
| Application | Ultrasonic plastics assembly, welding, staking, inserting |
| Series | See label |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Manufacturer Sonics
Part Number U-B2224
Shelf J-127
Model U-B2224
MPN U-B2224
Type Ultrasonic Welding Booster
