Product Description
The Turck BI5-EM18-AP6/S907 is an inductive proximity sensor designed for high-temperature environments, rated for continuous operation up to +160°C. It features an M18 x 1 stainless steel (1.4571 / AISI 316Ti) threaded barrel with flush mounting, a 5mm rated switching distance, and a 3-wire PNP normally open (NO) output. The S907 special version designates the extended temperature range capability, making it suitable for demanding applications such as food processing, packaging, and high-heat industrial environments.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | turck |
| Model / Part Number | Bi5-em18-ap6/s907 |
| Manufacturer ID | 4617425 |
| Product Description | Inductive Sensor – With Increased Temperature Range |
| Series | BI5-EM18 |
| Special Version | S907 (Max. ambient temperature = 160°C) |
| Sensing Distance (Rated Sn) | 5 mm |
| Mounting Conditions | Flush (Embeddable) |
| Secured Operating Distance | ≤ 0.81 × Sn (≤ 4.05 mm) |
| Repeat Accuracy | ≤ 2% of full scale |
| Temperature Drift | ≤ ±20% |
| Hysteresis | 3…15% |
| Operating Voltage (UB) | 10…30 VDC |
| Ripple (Uss) | ≤ 10% UBmax |
| DC Rated Operating Current (Ie) | ≤ 200 mA |
| No-Load Current | ≤ 15 mA |
| Residual Current | ≤ 0.1 mA |
| Isolation Test Voltage | 0.5 kV |
| Voltage Drop at Ie | ≤ 1.8 V |
| Short-Circuit Protection | Yes / Cyclic |
| Reverse Polarity Protection | Yes / Complete |
| Output Type | 3-Wire DC, PNP, Normally Open (NO) |
| Switching Frequency | 200 Hz max. |
| Correction Factors | St37 = 1; Al = 0.3; Stainless Steel = 0.7; Brass = 0.4 |
| Housing Material | Stainless Steel 1.4571 (AISI 316Ti) |
| Active Area Material | Plastic, PEEK |
| End Cap Material | Plastic, PTFE |
| Barrel Size / Thread | M18 x 1, Partially Threaded |
| Overall Dimensions (Length) | 95 mm |
| Max. Tightening Torque | 25 Nm |
| Admissible Pressure on Front Cap | ≤ 10 bar |
| Electrical Connection | Cable (Flying Leads / Bare End) |
| Cable Quality | Ø 3.7 mm, PTFE/FEP jacketed, 2 m standard |
| Core Cross-Section | 3 × 0.34 mm² |
| Ambient Temperature Range | -25°C … +160°C |
| Protection Class (IP Rating) | IP68, IP69K |
| LED Indicator | None (embeddable special version without LED) |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type PNP
Sensor Type Inductive
Operating Distance 5 mm
Full Load Amps ≤ 0.1 mA
Manufacturer Turck
Enclosure Type IP68, IP69K
Part Number BI5-EM18-AP6/S907
Shelf 0-9
Model BI5-EM18-AP6/S907
MPN BI5-EM18-AP6/S907
Type Inductive Proximity Sensor
