Product Description
The AMI UCFC210 is a piloted flange cartridge bearing unit designed for industrial machinery applications. This mounted ball bearing unit features a spherical outer diameter insert bearing in a 4-bolt cast iron housing with set screw locking mechanism for secure shaft mounting.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | AMI |
| Model/Part Number | UCFC210 |
| Product Type | Piloted Flange Cartridge Unit |
| Bore Diameter | 50mm |
| Housing Material | Cast Iron |
| Overall Length | 165mm |
| Overall Height | 42.6mm |
| Length Through Bore | 51.6mm |
| Pilot Diameter | 110mm |
| Bolt Circle Diameter | 138mm |
| Bolt Size | M14 |
| Locking Device | Set Screw |
| Insert Bearing | UC210 |
| Dynamic Load Rating | 3600 kgf |
| Static Load Rating | 2370 kgf |
| Seal Type | Contact Seal with Flinger |
| Lubrication | Relubricatable |
| Series | UCFC200 |
| Expansion Type | Non-Expansion (Fixed) |
| Weight | 6.08 lbs |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Material 52100 Bearing Steel
Manufacturer Ami
Part Number UCFC210
Shelf GS-34
Bore Diameter 50 mm
Model UCFC210
MPN UCFC210
Type Pillow Block
