Product Description
The Destaco 82M-3ND0006NL8 is a heavy-duty enclosed pneumatic power clamp from the 82M-3E Series, designed for demanding workholding and fixture applications. This unit features NAAMS-compliant mounting (Size 63), a long drive (D0) shaft configured for lateral (side) clamping arms, 63mm cylinder bore with 1/4-18 NPT air ports, no hand lever, and a PNP sensor with an in-line M12x1 connector for position feedback. The 82M-3E Series offers field-adjustable opening angles up to 135°, multiple mounting surfaces, and a manual unlocking feature in case of air pressure loss.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Destaco |
| Model / Part Number | 82M-3ND0006NL8 |
| Product Type | Enclosed Pneumatic Power Clamp |
| Product Series | 82M-3E |
| Cylinder Action | Double Acting |
| Cylinder Type | Pneumatic |
| Suitable Media | Air |
| Cylinder Bore Size | 63 mm (2.48 in) |
| Mounting Style | NAAMS (Size 63 only) |
| Clamp Arm Shaft Type | D0 – Long Drive Shaft, for Lateral (Side) Arms |
| Shaft Size | 26 mm |
| Clamp Arm Style | Lateral (Side) Arms |
| Port Size / Type | 1/4-18 NPT |
| Hand Lever | No Hand Lever |
| Sensor Type | PNP Sensor with In-line M12x1 Connector (L8) |
| Sensor Replacement Part | 8EA-146-1 |
| Opening Angle (Adjustable) | 5° – 135° |
| Max Holding Torque | 1800 Nm (1,325 ft-lb) |
| Max Clamping Torque | 420 Nm (310 ft-lb) at 5 bar (72 psi) |
| Max Operating Pressure | 6 bar (87 psi) |
| Air Consumption per Double Stroke at 72 psi | 0.07 ft³ |
| Body Material | Enclosed Aluminum Body |
| Air Supply Requirement | Oil-free air permissible |
| Manual Unlock | Yes – Manual unlocking in case of air pressure loss |
| Weight | Approx. 8.36 lb (3.8 kg) |
| NAAMS / Euro Standard Compliant | Yes |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Mounting Style NAAMS
Sensor Type PNP Sensor with In-line M12x1 Connector
Torque 1800 Nm (1,325 ft-lb)
Max. Bar 6 bar
Max. PSI 87 psi (6 bar)
Manufacturer Destaco
Shaft Diameter 26 mm
Empty Weight 8.36 lb (3.8 kg)
Part Number 82M-3ND0006NL8
Series 82M-3E
Shelf L-4
Bore Diameter 63 mm (2.48 in)
Model 82M-3ND0006NL8
Port Size 1/4-18 NPT
MPN 82M-3ND0006NL8
Type Pneumatic Cylinder
