Product Description
The Allen-Bradley 100-C09D*10 is a 3-pole IEC rated contactor designed for motor control applications. This compact contactor is rated for 9 amperes with a 120VAC operating coil and includes one normally open auxiliary contact for control circuit feedback.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Allen-Bradley |
| Model/Part Number | 100-C09D*10 |
| Type | IEC Contactor |
| Current Rating | 9 Amp AC-3, 32 Amp AC-1 |
| Coil Voltage | 110V 50Hz / 120V 60Hz |
| Poles | 3 Normally Open |
| Auxiliary Contacts | 1 Normally Open |
| Horsepower Rating | 2 HP @ 230V, 5 HP @ 460V |
| Power Rating | 4 kW |
| Voltage Rating | 230-690 VAC 50Hz, 115-575 VAC 60Hz |
| Terminal Type | Screw Terminals |
| Mounting Style | DIN Rail Mount |
| Frequency | 50/60 Hz |
| Weight | 0.85 lbs |
| Series | 100-C |
| Standards Compliance | UL Listed, CE, CSA, IEC/EN 60947-4-1 |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686185
Mounting Style DIN Rail Mount
Current Rating 9 AMP AC-3, 32 AMP AC-1
Manufacturer Allen-Bradley
Part Number 100-C09D*10
Series 100-C
Shelf C-14
Model 100-C09D*10
Coil Voltage 120VAC
Horsepower 2 HP @ 230V, 5 HP @ 460V
MPN 100-C09D*10
Type Contactor
