Product Description
The Contrinex DW-AD703-M8 is an Extreme Full Inox Series 700 inductive proximity sensor featuring an M8 threaded stainless steel barrel. It delivers reliable non-contact detection of metallic targets with a 6mm nominal sensing range (actual sensing radius: 2.43mm) in a non-embeddable (non-flush) mounting configuration. The sensor operates on 3-wire DC with a PNP normally open output and supports IO-Link communication for smart factory integration.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Contrinex |
| Model / Part Number | DW-AD703-M8 |
| Manufacturer Part Number (MPN) | DW-AD-703-M8 |
| Contrinex Order Code | 330-320-000 |
| Product Series | Extreme Full Inox Series 700 |
| Sensor Type | Inductive Proximity Sensor |
| Thread Size / Housing | M8 x 1 mm (Threaded Barrel) |
| Sensing Range (Sn) | 6 mm |
| Mounting Type | Non-Embeddable (Non-Flush / Unshielded per Radwell; Shielded per some distributors — see note) |
| Output Type | PNP, Normally Open (N.O.) |
| Interface / Communication | IO-Link |
| Wiring | 3-Wire DC |
| Connection / Cable | PUR Cable, 2 m, 3-Wire |
| Supply Voltage | 10 … 30 VDC |
| Current Type | DC |
| Max Output Current | 200 mA |
| Housing Material | Stainless Steel V2A / 1.4305 / AISI 303 (Full Inox) |
| Body Length | 22 mm |
| Enclosure / IP Rating | IP68 / IP69K |
| Operating Temperature | -25 … +85 °C |
| Switching Frequency (max) | 1200 Hz |
| Weight | 42 g |
| RoHS Compliant | Yes |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type PNP
Sensor Type Inductive
Country/Region of Manufacture Switzerland
Operating Distance 6 mm
Full Load Amps 200 mA
Manufacturer Contrinex
Enclosure Type IP68 / IP69K
Part Number DW-AD703-M8
Shelf K-50
Model DW-AD703-M8
MPN DW-AD703-M8
Type Inductive Proximity Sensor
