Product Description
The Contrinex DW-AS-701-M18-303 is an Extreme Stainless (Full Inox) M18 threaded barrel inductive proximity sensor featuring a one-piece stainless steel V2A housing with a 10 mm sensing range and NPN Normally Open (N.O.) 3-wire DC output. It connects via an S12 (3-pin) connector and is rated IP68/IP69K, making it highly resistant to water immersion and high-pressure washdown environments. The shielded (embeddable/flush) design allows installation directly in metal without performance degradation, making it ideal for demanding industrial automation applications.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Contrinex |
| Model / Part Number | DW-AS-701-M18-303 |
| Product Type | Inductive Proximity Sensor |
| Series | DW-AS (Extreme Stainless / Full Inox) |
| Housing Size / Thread | M18 x 1 |
| Sensing Range (Sn) | 10 mm |
| Mounting Type | Embeddable (Flush / Shielded) |
| Output Polarity | NPN |
| Output Function | Normally Open (N.O.) |
| Wiring Type | 3-Wire DC |
| Connection Type | S12 Connector (3-pin) |
| Supply Voltage | 10 to 30 VDC |
| Max Load Current | ≤ 200 mA |
| No-Load Supply Current | ≤ 10 mA |
| Voltage Drop | ≤ 2 V dc |
| Max Switching Frequency | ≤ 100 Hz |
| Repeat Accuracy | ≤ 0.3 mm |
| Temperature Drift | ≤ 10% |
| Housing Material | Stainless Steel V2A (1.4305 / AISI 303) |
| Sensor Face Material | V2A 1.4305 AISI 303 Stainless Steel |
| IP Rating | IP68 / IP69K |
| Sensor Height (Body Length) | 63.5 mm |
| Max Tightening Torque | 50 Nm |
| Weight | 53 g |
| Standard Sensing Object | 30 x 30 x 1 mm Fe |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686161
Output Type NPN
Sensor Type Inductive
Operating Distance 10 mm
Full Load Amps ≤ 10 mA
Manufacturer Contrinex
Enclosure Type IP68 / IP69K
Part Number DW-AS-701-M18-303
Shelf K-16
Model DW-AS-701-M18-303
MPN DW-AS-701-M18-303
Type Inductive Proximity Sensor
